Clearplay Plus Amp

Clearplay Plus Audio System Amp

Replaces BBA2 models (SKU: 59062 and 59089). Works with all Spa Touch and TP topside control panels in BP control systems. Bluetooth audio streaming allowing control directly from the spa with Spa Touch topside controllers, and from your smartphone for both touchscreen and non touchscreen TP topside controllers. Compatible with iOS and Android phones or tablets.

Specifications:

• Built In Power Supply: AV Port on BP Control Systems
• Dimensions: L: 7.94", H: 6.24", W: 1.91"
• Impedance: 2-8 Ohms
• Input Voltage: 110v - 240v
• Hertz: 50/60Hz
• Weight: 3lbs
• Output Power 120w RMS:
  • (4 ohm load) 4x30W (42W max)
  • (8 ohm load) 4x15W (18W max)
• 4 Channel Amp Configurations:
  • Option 1: Sub-woofer from the rear and 2 channels.
  • Option 2: 4 channels.

Follow this link for the complete user guide:

https://www.balboawater.com/wp-content/uploads/2024/08/bba3-user-guide_42384-rev-A_English.pdf
